Description
| Item Type: |
Force Sensor |
|---|---|
| Model No.: |
A301/1 |
| Thickness (mm): |
0.203 |
| Operating Voltage (VDC): |
0.25 to 1.25 |
| Force Range |
0-111N (0 – 11 Kg) |
| Length (mm): |
25.4 mm |
| Width (mm): |
14 |
| Connector: |
2-pin Male Square Pin |
| Pin Spacing (mm) |
2.54 |
| Sensing Area (mm) |
9.53 |
| Surface Layer |
Polyester |
| Max Current (A) |
0.2 |
| Drift |
< 5% per logarithmic time scale |
| Hysteresis: |
< 4.5 % of full scale |
| Linearity (Error) |
< ±3% of full scale |
| Repeatability Same part |
< ±2.5% |
| Response Time (uS) |
5 |
| Operating Temperature (°C): |
-40 to 60 |
| RoHS Compliant |
Yes |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 8 × 2 × 1 cm |
