REES52 Raspberry Pi 7 Inch Capacitive Touch Screen LCD(C) HDMI Interface Display HDMI Display Monitor 7-inch 800x480 HD TFT LCD with Touch Screen for Raspberry Pi B+/2B / 3B/4B

The 7 Inch LCD Touch Display With Driver Board Kit For Raspberry Pi gives users the ability to create an all-in-one, integrated projects such as tablets, infotainment systems, and embedded projects. The 800×480 physical resolution (resolution range can be adjusted between 640 x 480 to 1600 x 1200) display connects via an adapter board which handles power and signal conversion. Only two connections to the Pi are required; power from the Pi’s GPIO port and a ribbon cable that connects to the DSI port present on all Raspberry Pi’s. Touchscreen drivers with support for 10-finger touch and an on-screen keyboard will be integrated into the latest Raspbian OS for full functionality without a physical keyboard or mouse.

Specification:
Screen Diagonal: 7.0 inch
Active Area: 154.08(W) × 85.92(H) mm
Resolution: 800 x 480
Dot Pitch: 0.0642(W) × 0.1790(H) mm
Pixel Arrangement: R.G.B. Vertical Stripe
Viewing angle: 140/120
Display Mode: Normally White
Contrast Ratio: 500:1
Brightness: 250 Units
Physical Size: 164.9(W) ×100.0(H) ×5.7(D) mm
Electrical Interface: Digital
Backlight Panel: LED
Surface Treatment: Anti-Glare
Operating Voltage: 5V DC
Rated Power: 6-7W
Signal Input Source: 1 HDMI only
System Production: PAL/NTSC

Package Included:
1 x 7 inch LCD display
1 x USB cable for the Touch Screen
1 x HDMI to HDMI cable
